Flowdot FYPR 8464 Module Model No:93NK3 Part No:78DH24

Operating Environment

■     Installation should be indoors with no direct sun light and should have a maximum ambient room temperature of 113˚F (45˚C).

Quality Assurance Standards

■    CE marked. Each module is factory tested to meet strict industry standards and is manufactured in an ISO 9001 and ISO 14000 quality and environmental management system.

Features

■ Cost effective CPVC spacers for Mining EDI.

■    Double O-ring seal guarantees  leak-free operation.

■ Generate mixed-bed quality deionized water without the use of chemicals.

■ No need for acid/caustic, neutralization system or exchangeable DI tanks.

■ Continuous production instead of batch,with consistent quality.

■ Superior electrical isolation.

■ 100 psi (7 bar), 113˚F (45˚C) continuous operation.

■ Proprietary all-filled concentrating compartments eliminate recirculation pump and brine injection.

■ Significantly lower operating costs, than conventional ion exchange.

  Operational Data
